Installation/Operation Supplement
21 F232145 (EN)
Electrical Specifications
50 Pound Capacity Models
Voltage Designation Standard Electric Heat
Co
de
Vo
lt
a
g
e
Cyc
le
Phase
Wir
e
Full Lo
ad
Amps Ci
rc
ui
t
Br
eak
er
AW
G
mm
2
Full Lo
ad
Amps Ci
rc
ui
t
Br
eak
er
AW
G
mm
2
2 Speed Models
C 380 – 415 50 3 4 6 15 14 2.5 39 50 6 16
D 220 – 240 50 3 3 12 20 12 4 64 70 4 25
E 220 – 240 50 1 2 15 30 10 6 37 40 8 10
F 440 – 480 60 3 3 6 15 14 2.5 39 50 6 16
J 200 50 3 3 10 20 12 3 x 4 N/A
O 208 – 240 60 3 3 10 20 12 4 64 70 4 25
Y* 208 – 240 60 1 2 15 30 10 6 37 40 8 10
Variable-Speed Models
N 440 – 480 50/60 3 3 4 15 14 2.5 41.6 45 8 10
P 380 – 415 50/60 3 3 4 15 14 2.5 36.5 40 8 10
Q 200 – 240 50/60 3 3 6.3 15 14 2.5 62.6 70 4 25
T 200 – 240 50/60 1 2 6.3 15 14 2.5 N/A
X 200 – 240 50/60 1 or 3 2 or 3 6.3/6.3 15 14 2x2.5
3x2.5 N/A
NOTE: Wire sizes shown are for copper, THHN, 90° conductor per NEC article 310.
*Coin models only.
Table 11
