Alliance Laundry Systems Washer-Extractor - Manual (Page 25)

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Installation/Operation Supplement
23 F232145 (EN)
Electrical Specifications
80 Pound Capacity Models
Voltage Designation Standard Electric Heat
Co
de
Vo
lt
a
g
e
Cyc
le
Phase
Wir
e
Full Lo
ad
Amps Ci
rc
ui
t
Br
eak
er
AW
G
mm
2
Full Lo
ad
Amps Ci
rc
ui
t
Br
eak
er
AW
G
mm
2
Variable-Speed Models
N 440 – 480 50/60 3 3 4.5 15 14 2.5 42 45 8 10
P 380 – 415 50/60 3 3 4.5 15 14 2.5 37 40 8 10
Q 200 – 240 50/60 3 3 12.4 20 12 4 87.4 90 2 35
NOTE: Wire sizes shown are for copper, THHN, 90° conductor per NEC article 310.
Table 13
Electrical Specifications
125 Pound Capacity Models
Voltage Designation Standard Electric Heat
Code
Vo
lt
a
g
e
Cy
c
le
Ph
ase
Wi
re
Fu
ll Loa
d
Amps Cir
c
uit
Bre
ake
r
AW
G
mm
2
Fu
ll Loa
d
Amps Cir
c
uit
Bre
ake
r
AW
G
mm
2
Variable-Speed Models
N 440 – 480 50/60 3 3 5.1 15 14 2.5 N/A
P 380 – 415 50/60 3 3 5.1 15 14 2.5 N/A
Q 200 – 240 50/60 3 3 7.9 25 10 6 N/A
NOTE: Wire sizes shown are for copper, THHN, 90° conductor per NEC article 310.
Table 14
