Installation/Operation Supplement
9 F232145 (EN)
Table 3 (Continued)
Drive Train Information
Number of motors in drive train 1 1 1 1 1 1 1 1
Drive motor power, HP (kW) 2
(1.5)
2
(1.5)
2
(1.5)
2
(1.5)
2
(1.5)
3
(2.2)
5
(3.7)
7.5
(5.6)
Cylinder Speeds
Gentle wash/reverse speed, RPM 29 27 26 26 24 24 22 27
Wash/reverse speed, RPM 52 48 46 47 43 43 40 37
Distribution speed, RPM 82 86 73 73 68 77 63 62
Low extract speed, RPM 366 343 328 328 307 307 280 260
Medium extract speed, RPM
(Not available on Electronic Control models.) 534 500 478 478 447 447 408 380
High extract speed, RPM 685 641 613 614 573 574 524 485
Centrifugal Force Data
Gentle wash centrifugal force, Gs 0.25 0.25 0.25 0.25 0.25 0.25 0.25 0.43
Wash/reverse centrifugal force, Gs 0.8 0.8 0.8 0.8 0.8 0.8 0.8 0.8
Distribution centrifugal force, Gs 2 2 2 2 2 2 2 2
Low extract centrifugal force, Gs 40 40 40 40 40 40 40 40
Medium extract centrifugal force, Gs 85 85 85 85 85 85 85 85
High extract centrifugal force, Gs 140 140 140 140 140 140 140 140
Balance Detection
Vibration switch installed* Standard Standard Standard Standard Standard Standard Standard Standard
Direct Steam Heating (Optional)
Steam inlet connection size,
in. (mm) 1/2
(13)
1/2
(13)
1/2
(13)
1/2
(13)
1/2
(13)
1/2
(13)
1/2
(13)
3/4
(19)
Number of steam inlets 1 1 1 1 1 1 1 1
Steam required to raise bath water
temperature 10
° F (6°C), lbs. (kg)
LOW 0.62
(0.28)
0.92
(0.42)
2.1
(1.51)
2.09
(1.51)
2.8
(2.0)
3.6
(1.63)
4.1
(2.93)
6.8
(4.9)
HIGH 0.88
(0.4)
1.31
(0.6)
2.69
(1.96)
2.84
(2.04)
3.6
(2.59)
5.5
(2.49)
6.0
(4.34)
8.9
(6.4)
Average steam use per cycle, bhp (kg) 0.54
(8.3)
0.73
(11.3)
1.4
(21.6)
1.43
(22.4)
1.8
(28.9)
2.32
(36.4)
2.93
(45.9)
4.5
(71)
Electrical Heating (Optional)
Total electrical heating capacity, kW 7.8 7.8 15.6 15.6 23.4 23.4 31.2 N/A
Electrical heating elements 3 3 6 3 9 9 12 N/A
Electrical heat element size, kW 2.6 2.6 2.6 5.2 2.6 2.6 2.6 N/A
* Refer to Gap Setting for Vibration Switch (Variable-Speed and Fixed-Speed Models) section for specifications.
