– Horizontal positioning
LBT-GPX555/MHC-GPX555 only
Line Array Speaker System
(MHC-GPX888 only)
To create a party environment, we
recommend you to install your speakers
using Line Array Speaker System. It
provides a wide sound space for a large
room like a hall.
– Positioning
– Installing
1
Insert the pins of the spacer
(supplied) to the catcher holes on
top of the subwoofer.
2
Stack the front right speaker on top
of the subwoofer. Make sure the
pins of the spacer are inserted into
catcher holes on the front right
speaker.
3
Repeat steps 1 and 2 to install
another subwoofer and front left
speaker.
