Hooking up the system securely
Getting Started
* B and D are different
depending on the model.
See below.
BLACK BLACK GRAY GRAY
BLACK GRAY GRAY
1
2
3
4
1 3 4 2
5 1
2
1 5 2
MHC-GPX888
LBT-GPX555/MHC-GPX555
MHC-GPX888
LBT-GPX555/MHC-GPX555
1 To front speaker (left)
2 To front speaker (right)
3 To subwoofer (left)
4 To subwoofer (right)
5 To subwoofer
