Inserting a floppy disk
• Size: 3.5 inch
• Type: 2HD (1.44 MB)
• Format: MS-DOS format (512 bytes
×
18 sectors)
Notes
• Do not insert the media other than the floppy disks described above.
• You cannot use the optional MSAC-FD2M/FD2MA Floppy Disk Adaptor for Memory Stick.
• Never remove the floppy disk, turn off the power, or change the position of the MS/FD selector
while the access lamp is lit up.
While sliding the EJECT lock to the left, slide down the DISK EJECT lever.
1 Check that the write protect tab is set to the recordable position for
recording
.
2 Insert the floppy disk until it clicks.
Usable floppy disks
Removing the floppy disk
1
2
DISK EJECT lever EJECT lock
Unrecordable/unerasable
Recordable/erasable
