* Depending on the sound field settings and the source,
there may be no sound output.
Inputs (Analog)
TV, VIDEO 1
Sensitivity: 550 mV
Impedance: 33 kohms
Inputs (Digital)
TV, VIDEO 2
Optical
VIDEO 3
Coaxial, optical
HDMI section
Connector
HDMI™ connector
Video inputs/outputs
BD, DVD, SAT/CATV:
640 × 480p@60 Hz
720 × [email protected]/60 Hz
1280 × [email protected]/60 Hz
1920 × [email protected]/
60 Hz
1920 × [email protected]/
60 Hz
720 × 576p@50 Hz
1280 × 720p@50 Hz
1920 × 1080i@50 Hz
1920 × 1080p@50 Hz
1920 × 1080p@24 Hz
Audio inputs
BD, DVD, SAT/CATV:
Linear PCM 7.1ch/
Dolby Digital/DTS
Tuner section
System
PLL quartz-locked digital
synthesizer
FM tuner section
Tuning range
87.5 MHz - 108.0 MHz
(100 kHz step)
Antenna (aerial)
FM wire antenna (aerial)
Antenna (aerial) terminals 75 ohms, unbalanced
Intermediate frequency
10.7 MHz
AM tuner section
Tuning range
530 kHz - 1,710 kHz (with
the interval set at 10 kHz)
531 kHz - 1,710 kHz (with
the interval set at 9 kHz)
Antenna (aerial)
AM loop antenna (aerial)
Intermediate frequency
450 kHz
Video section
Inputs
VIDEO: 1 Vp-p 75 ohms
COMPONENT:
Y: 1 Vp-p 75 ohms
P
B
/C
B
, P
R
/C
R
: 0.7 Vp-p
75 ohms
Speaker (SS-CT500)
Speaker system
Full range, Bass reflex
(front speaker part), Full
range, Acoustic suspension
(center speaker part)
Speaker unit
50 mm (2 in) cone type
Rated impedance
4 ohms
Dimensions (approx.)
957 mm × 90 mm × 51 mm
(37
3
/
4
in × 3
5
/
8
in × 2
1
/
8
in) (w/h/d)
Mass (approx.)
1.9 kg (4 lb 4 oz)
Speaker cords
3 m (118
1
/
8
in)
Subwoofer (SA-WCT500)
Speaker system
Subwoofer, Bass reflex
Speaker unit
130 mm (5
1
/
8
in) cone type
Rated impedance
4 ohms
Dimensions (approx.)
212 mm × 374 mm × 364
mm (8
3
/
8
in × 14
3
/
4
in ×
14
3
/
8
in) (w/h/d)
Mass (approx.)
9.1 kg (20 lb 1oz)
WS-CT500EB
Extension bracket
Dimensions (approx.)
286 mm × 179 mm × 60
mm (11
3
/
8
in ×7
1
/
8
in ×
2
3
/
8
in) (w/h/d)
Mass (approx.)
1.3 kg (2 lb 14 oz)
Rear cover
Dimensions (approx.)
294 mm × 185 mm × 67
mm (11
5
/
8
in × 7
3
/
8
in ×
2
3
/
4
in) (w/h/d)
Mass (approx.)
0.56 kg (1lb 4oz)
General
Power requirements
120 V AC, 60 Hz
Power consumption
On: 110 W
Standby mode: 0.3 W (when “CTRL: HDMI”
and “S-AIR STBY” are set to “OFF.”)
Power output
(DIGITAL MEDIA PORT) DC OUT: 5 V, 700 mA
Design and specifications are subject to change without
notice.
• Standby power consumption 0.3 W.
• Halogenated flame retardants are not used in the
certain printed wiring boards.
• Over 85 % power efficiency of amplifier block is
achieved with the full digital amplifier, S-master.
