SIRIUS – Tactile Keypad

17

DAS-SIRIUS Sirius Satellite Radio Tuner Module

SIRIUS – Tactile Keypad

FIG. 33 shows the navigation button layout for Tactile Keypads.

SIRIUS Source Control

When the Source type = SIRIUS, the navigation buttons perform the following functions:

FIG. 33

Tactile Keypad

• NAV UP

NEXT Channel/Station (Ch 9, 10, 11 etc.)

• NAV DOWN

PREV Channel/Station (Ch 9, 8, 7 etc.)

• NAV RIGHT

NEXT PRESET (Preset 1, 2, 3…)

• NAV LEFT

PREV PRESET (Preset 1, 10, 9, 8…)

• NAV CENTRE

NOT USED

• NAV CENTRE Hold NOT USED

Nav Up

Nav Down

Nav Right

Nav Left
