Controlling SIRIUS via the LCD Keypad
12 DAS-SIRIUS Sirius Satellite Radio Tuner Module
Selecting SIRIUS as the Audio Source
On the Home screen, SIRIUS will appear in the top left touch field and is considered to be Source 1 (FIG. 24).
To turn ON the SIRIUS source, touch the text “SIRIUS”. The screen will change to the SIRIUS
Main Screen and the
> icon appears in front of the text to indicate that SIRIUS is ON in that room.
Volume UP to the desired volume level.
SIRIUS SAT Main screen
There are two lines of metadata display on the LCD Keypad with a maximum display of 14 characters per line
(FIG. 25).
Display Line #1 Channel # & Channel Name
Channel # + Channel Name will be displayed up to a max. of 14 characters.
This display line scrolls once and stops.
Touch the line of text to update the text and scroll the info once.
Display Line #2 Artist Name, Song Title & Composer
The Artist, Song Title & Composer are displayed up to a max. of 14 characters.
This display line scrolls once and stops.
Touch the line of text to update the text and scroll the info once.
Channel - / Channel +
Touch Channel – to select the previous channel/station and begin playing.
Touch Channel+ to select the next channel/station and begin playing.
FIG. 24 LCD Keypad - Home screen
FIG. 25 LCD Keypad - SIRIUS SAT Main screen
Select SIRIUS (Source 1)
Display Line #1 - Channel #, Name
Display Line #2 - Artist, Song Title,
Channel Next Channel Prev
Display the Preset screen
where the user can select 1
of 10 available presets
Displays the
Home screen
Displays the SIRIUS
MORE screen
Composer
Display the Numeric screen where the
user can enter the channel number
directly
