Name
Function
H DTS (-ES)/
(96/24)
Lights up when the receiver is
decoding DTS signals.
“DTS-ES” lights up when the
receiver is decoding DTS-ES
signals.
“DTS 96/24” lights up when the
receiver is decoding DTS 96
kHz/24 bit signals.
Note
When playing a DTS format
disc, be sure that you have made
digital connections and that
INPUT MODE is not set to
“ANALOG” (page 78).
I CAT
Lights up when category mode
is set to “ONE CAT” during
XM Radio operation (page 73).
J MEMORY
Lights up when a memory
function, such as Preset
Memory (page 68), etc., is
activated.
K Tuner
indicators
Lights up when using the
receiver to tune in radio stations
(page 66), etc.
L Preset
station
indicators
Lights up when using the
receiver to tune in preset radio
stations. For details on
presetting radio stations, see
M D.RANGE
Lights up when dynamic range
compression is activated (page
N NEO:6
Lights up when DTS Neo:6
Cinema/Music decoder is
O COAX
Lights up when INPUT MODE
is set to “AUTO IN” and the
source signal is a digital signal
being input through the
COAXIAL jack, or when
INPUT MODE is set to “COAX
P HDMI
Lights up when the receiver
recognizes a component
connected via a HDMI IN jack
Name
Function
Q Playback
channel
indicators
L
R
C
SL
SR
S
SBL
SBR
SB
The letters (L, C, R, etc.)
indicate the channels being
played back. The boxes around
the letters vary to show how the
receiver downmixes the source
sound (based on the speaker
settings).
Front Left
Front Right
Center (monaural)
Surround Left
Surround Right
Surround (monaural or the
surround components obtained
by Pro Logic processing)
Surround Back Left
Surround Back Right
Surround Back (the surround
back components obtained by
6.1 channel decoding)
Example:
Recording format (Front/
Surround): 3/2.1
Output channel: When surround
speakers are set to “NO” (page
Sound Field: A.F.D. AUTO
SW
L
C
R
SL
SR
