Press AUTO CAL.
Measurement starts in 5 seconds and the
display changes as follows:
A. CAL [5] t A. CAL [4] t A. CAL [3] t
A. CAL [2] t A. CAL [1]
The measurement process will take
approximately 30 seconds to complete.
The table below shows the display when
measurement starts.
Note
You cannot measure the speaker height of the
surround speakers and the surround back speakers.
Set this value using the “SUR POS.” parameter in
the SYSTEM menu (page 59).
Tip
The measurements may not be performed correctly
or Auto Calibration cannot be performed when
special speakers, such as dipole speakers are used.
To cancel Auto Calibration
The Auto Calibration function will be
canceled when you do the following during the
measurement process:
– Press ?/1, input buttons or MUTING.
– Press SPEAKERS (OFF/A/B/A+B) on the
receiver.
– Change the volume level.
– Press AUTO CAL again.
– Connect the headphones.
1
Confirm the measurement
result.
When the measurement ends, a beep
sounds and the measurement result
appears on the display.
2
Press RECEIVER and then
press
V/v repeatedly to select
the item. Then, press .
Measurement for Display
Speaker existance TONE
Speaker gain, distance, frequency
response
T.S.P.
Sub woofer gain and distance WOOFER
Confirming/saving the
measurement results
Measurement
result Display Explanation
When the
measurement
process
completes
properly
SAVE Proceed to step
2.
When the
measurement
process fails
ERROR
XXXX
See “When
error codes
appear” (page
37).
Item Explanation
RETRY Performs the Auto
Calibration again.
SAVE Saves the measurement
results and exits the setting
process.
WARN CHK Displays warning
concerning the
measurement results. See
“When you select “WARN
CHK”” (page 38).
PHASE Displays the phase of each
speaker (in phase/out of
phase). See “When you
select “PHASE”” (page 38).
DISTANCE Displays the measurement
result for speaker distance.
LEVEL Displays the measurement
result for speaker level.
EXIT Exits the setting process
without saving the
measurement results.
