s E r V I c E
AR-7EVH Electric Rotisserie with Ventless Hood Operation & Care Manual • 33
Part numbers and drawings are subject to change without notice.
AR-7EVH Electric Rotisserie with Ventless Hood Operation & Care Manual • 33
Part numbers and drawings are subject to change without notice.
ModEl > curVEd door flat door
ItEM dEscrIptIon part no. Qty part no. Qty
1 PAn, DRIP 1001555 2 1001555 2
2 WASHER, STRAIn RELIEF 1002389 1 1002389 1
3 HInGE, UPPER, DOOR 1007672 1 1002596 1
4 HInGE, LOWER, DOOR 1007673 1 1002597 1
5 ASSEMBLy WELD, DRIP PAn 5001094 1 5001094 1
6 ASSEMBLy, LEG, 4" (102mm), ADjUSTABLE - set of 4 ( includes below items ) 5001765 1 5001765 1
LEG PLATE LG-26123 4 LG-26123 4
FEET, S/S, InSERT, ADjUSTABLE FE-26125 4 FE-26125 4
MOUnTInG SCREWS SC-2351 16 SC-2351 16
7 ASSEMBLy, DOOR, COnTROL SIDE 5005773 1 5009591 1
ASSEMBLy, DOOR, nOn-COnTROL SIDE 5006426 1 5009815 1
8 OUTER GLASS DOOR 5007824 1 — —
9 OPTIOn, SOLID BACK 5006214 1 5006214 1
10 ASSEMBLy, PAnELS stainless steel ( right - hand ) 5006461 1 5006461 1
( left - hand ) 5007085 1 5007085 1
burgundy ( right - hand ) 5006211 1 5006211 1
( left - hand ) 5007086 1 5007086 1
black ( right - hand ) 5006212 1 5006212 1
( left - hand ) 5009209 1 5009209 1
11 BUSHInG, STRAIn RELIEF, InT 208-240V, 1Ph BU-33505 1 BU-33505 1
208-240V, 3Ph; 380-415V BU-33948 1 BU-33948 1
12 CORD; 6-1/2 ft (1,981 m) 208-240V, 1Ph CD-33841 1 CD-33841 1
208-240V, 3ph CD-3987 1 CD-3987 1
13 ELEMEnT, RADIAnT, FIREBAR 208V EL-33974 1 EL-33974 1
230V; 240V; 380-415V EL-33973 1 EL-33973 1
14 ELEMEnT, 5kW, COnVECTIOn 208V EL-34106 1 EL-34106 1
230V; 240V; 380-415V EL-34107 1 EL-34107 1
15 PAnEL, OVERLAy deluxe PE-25738 1 PE-25738 1
standard PE-25869 1 PE-25869 1
InSERT CARD deluxe only PE-25740* 1 PE-25740* 1
16 RIVET, BLInD, #44, S/S RI-2100 2 RI-2100 2
17 WELDMEnT, SPIT, AnGLED SI-25934 7 SI-25934 7
18 DRIP TRAy, FROnT 1009063 1 1009063 1
r o t I s s E r I E , f u l l a s s E M b l y p a r t s l I s t
ModEl > curVEd door flat door
ItEM dEscrIptIon part no. Qty part no. Qty
19 HAnDLE, DOOR HD-26900 1 HD-26900 1
20 DOOR, OUTER GLASS 5007824 1 — —
21 DOOR, InnER GLASS control side 5006779 1 — —
non - control side 5008322 1 — —
fastEnErs rEQuIrEd
dEscrIptIon part no. Qty dEscrIptIon part no. Qty
WASHER, DOOR SPACE, BOTTOM 1002143 1 PIn, DOOR, BOTTOM PI-26352 1
WASHER, FLAT, M8 WS-22298 1 nUT, HEx jAM 5/16-18 nU-25897 1
SCREW, 5/16-18 x 5/8 SC-2900 3 SCREW, InSERT SC-25781 1
PIn, DOOR, TOP PI-26350 1 SCREW, 8-32 x 3/8 SC-22378 6
r o t I s s E r I E , d o o r a s s E M b l y p a r t s l I s t
( not shown )
( not shown )
