Take Apart Top Case - 42
6 Remove the
interconnect-to-logic
board cable from the
opening for the right
clutch.
7 Remove the top case.
Replacement Note:
Before
securing the top case to the
bottom case, thread the
interconnect-to-logic
board cable through the
opening for the right
clutch. Form a loop around
the EMI clip by wrapping
the cable from behind and
then over and under the clip.
Interconnect-to-Logic
Board Cable
Right Clutch
Opening
EMI Clip
