Apple Mac PowerBook 550c User Manual
Page 7
Basics
PowerBook Screw Matrix - 5
Legend for Macintosh PowerBook 550c Screws
1 Feet
2 Hard drive, keyboard, bottom case (middle front),
display assembly, floppy drive, daughterboard EMI
shield (top edge), inside edge of top case, right side panel
3 Display bezel, display, clutch, DAA
4 Trackpad cable and actuator, daughterboard EMI shield
(sides), motherboard standoff
5 Rear panel
6 Hard drive bracket
7 Inverter board, interconnect board
8 Bottom case (front corners), left side panel
9 Floppy drive bracket
