Inverter board – Apple Mac PowerBook 550c User Manual
Page 140
Take Apart
Inverter Board - 83
Inverter Board
Before you begin, remove
the following:
• Battery/PCMCIA module
• Clutch covers
• Display access cover
• Display assembly
• Display bezel assembly
Note:
The display EMI shield
covers the inverter board
and attaches to the display
with adhesive. Pry up the
shield carefully before
removing the inverter
board.
Inverter
Board
