Additional Information
Specifications
Amplifier section
Power output
Surround mode
Frequency
response
(DIN 1 kHz)
Front:
25 W+25 W/8 ohms
Centre:
25 W/8 ohms
(only in the PRO LOGIC
and THEATER modes)
Rear:
10 W+10 W/8 ohms
VIDEO 1 + 2, TV, AUX:
20 Hz - 20 kHz ±2 dB
Outputs
BASS BOOST
Inputs
Outputs
VIDEO 1 REC:
Voltage 150 mV,
Impedance 470 ohms
REAR, MIX:
Voltage: 1 V
Impedance: 1 kilohms
+7 dB at 60 Hz
VIDEO 1, VIDEO 2:
1 Vp-p 75 ohms
VIDEO 1 REC, TV:
1 Vp-p 75 ohms
Video section
Audio section
Inputs
Impedance
50 kilohms
Sensitivity
150 mV VIDEO 1,
VIDEO 2,
TV, AUX
Power
requirements
Power
consumption
Dimensions
Mass (Approx.)
Supplied
accessories
General
220-230 V AC, 50/60 Hz
110 W
430 x 95 x 280 mm
(17 x 3
3 / 4 x 11 1 / 8 inches)
4.6 kg
(10 lb 2 oz)
Remote controller
(remote) (1)
Size AA (R6) batteries (2)
Design and specifications are subject to
change without notice.
