ASUS M3N WS 2-19
2.5.4 PCI slots
The PCI slots support cards such as a LAN card, SCSI card, USB card, and other
cards that comply with PCI specifications. Refer to the figure on the next page for
the location of the slots.
2.5.5 PCI-X slot
The PCI-X slot supports cards such as a LAN card, SCSI card, USB card, and
other cards that comply with PCI-X 1.0 specifications. Refer to the figure below for Refer to the figure below for
the location of the slot.
2.5.6 PCI Express x1 slots
This motherboard supports PCI Express x1 network cards, SCSI cards and other
cards that comply with the PCI Express specifications. Refer to the figure on the
next page for the location of the slots.
2.5.7 PCI Express 2.0 x16 slot
This motherboard supports PCI Express 2.0 x16 graphics cards that complies with
the PCI Express specifications. Refer to the figure below for the location of the slot.
PCI Express x1_1 slot
PCI_1 slot
PCI-X slot
PCI Express 2.0 x16_1 slot
PCI Express x1_2 slot
PCI_2 slot
