Entering the nvidia, Mediashield bios raid utility – Asus M3N WS User Manual
Page 149
ASUS M3N WS
4-37
Entering the NVIDIA
®
MediaShield BIOS RAID utility
To enter the NVIDIA
®
MediaShield BIOS RAID utility
1. Boot up your computer.
2. During POST, press
The RAID BIOS setup screens shown in this section are for reference only, and
may not exactly match the items on your screen.
At the bottom of the screen are the navigation keys. These keys allow you to move
through and select menu options.
[ESC] Quit [F6] Back [F7] Finish [TAB] Navigate [↑↓] Select [ENTER] Popup
MediaShield BIOS Dec 13 2007
- Define a New Array -
RAID Mode:
Mirrored
Striping Block:
Optimal
Free Disks
Array Disks
Port Disk Model Capacity Port Disk Model Capacity
0.0. WDC WD2500AAJS 232.88GB
0.1. WDC WD2500AAJS 232.88GB
[→] Add
1.0. WDC WD2500AAJS 232.88GB
1.1. WDC WD2500AAJS 232.88GB
[←] Del
