ASUS M3N WS 4-39
Rebuilding a RAID array
To rebuild a RAID array
1. From the Array List screen, use the up or down arrow keys to select a RAID
array, and then press . The RAID Array details appear.
A new set of navigation keys is displayed on the bottom of the screen.
7. Press to save settings and exit.
[Ctrl-X] Exit [↑↓] Select [B] Set Bootable [N] New Array [ENTER] Detail
Mediashield BIOS Dec 13 2007
- Array List -
Boot Status Vendor Array Size
Healthy NVIDIA MIRROR 149.04G
The Array List screen appears, where you can review the RAID arrays that
you have set up.
[R] Rebuild [D] Delete [C] Clear MBR [ENTER] Return
Array 4 : NVIDIA MIRROR 149.04G
- Array Detail -
RAID Mode: Mirrored
Striping Width: 1 Striping Block: 64K
Port Index Disk Model Capacity
0.0 0 WDC1600AAJS-22PSA0 149.05G
0.1 1 WDC1600AAJS-22PSA0 149.05G
A new set of navigation keys is displayed on the bottom of the screen.
