36 Installation and Operation Guide
3 Splitter Configurations
Figure 15 Restrictor and column connections
Column exit
Restrictor 1
to Detector 1
Restrictor 2
to Detector 2
To makeup
gas supply
C A U T I O N
Do not overtighten the fittings. The dashed line in Figure 16 (about 15° clockwise from
finger-tight) is usually enough.
