Hardware Installation 2
Installation and Operation Guide 19
3 This exposes a layer of soft insulation. Remove it to expose the hard oven
insulation. Remove the precut insulation piece at the location shown in
Figure 4 .
4 Replace the soft insulation. Install the valve box blanking plate, using one
screw at the front and one at the rear to secure it. See Figure 5 .
Figure 4 Remove the insulation cutout
Figure 5 Install valve box blanking plate
Remove
this
cutout
Two screws
