Karcher IVC 60-30 Tact H Z22 EU - Manual (Page 25)

– 10
Technical specifications
Type IVC 60/30 Ap M Z22
Mains voltage V 400
Frequency Hz 3~ 50
Rated power W 3000
Container capacity l 60
Air quantity (max.) with a suction hose length of 3 m m 3 /h 177
Air quantity (max.) with a suction hose length of 8 m m 3 /h 136
Negative pressure (max.) kPa (mbar) 25,0 (250)
Type of protection -- IP 54
Protective class -- I
Suction hose connection (C-DN/C-ID) DN 72
Nominal width of suction hose DN 42
Length x width x height mm 970 x 690 x 1240
Filter area m 2 1,9
Typical operating weight kg 95
Ambient temperature °C -10...+40
Maximum surface temperature °C 125
Relative air humidity % 30-90
Ignition protection class II 3D Ex tc IIIC
T125 °C Dc
Values determined to EN 60335-2-69
Sound pressure level L
pA
dB(A) 77
Uncertainty K
pA
dB(A) 1
Hand-arm vibration value m/s 2 <2,5
Uncertainty K m/s 2 0,2
Power cord H07RN-F 5x1,5 mm 2
Part no.: Cable
length
EU 6.649-826.0 7.5 m
25 EN
