– 2
1 Tension lever
2 Filter cover
3 Flat fold filter
4 Right unlocking of the placement me-
chanics
5 Power cord
6 Locking of the suction head (by means
of safety screw)
7 Filter dedusting
8 Steering roller of the dirt container
9 Pressure equalisation
10 Coupling for pressure balancing
11 Dirt receptacle
12 Intermediate ring
13 Left unlocking of the placement me-
chanics
14 Nameplate
15 Wheel
16 Suction support
17 Connection bushing
18 Steering roller of the chassis with park-
ing brake
19 Floor nozzle holder
20 Chassis
21 Drain pan
22 Handle of the dirt container
23 Holder for suction pipe
24 Handle of the suction head
25 Rotating knob
26 Suction head
27 Torque motor
28 Exhaust muffler
29 Push handle
30 Cable hook
31 Pilot lamp "negative pressure"
32 Pilot lamp "phase and rotary field fault"
33 ”Ready for use” indicator lamp
34 Spring bow for earthing
WARNING: This unit contains
hazardous dust. Emptying and
maintenance, including the re-
moval of the dust bag, may only
be carried out by someone who is familiar
with the unit and is wearing suitable protec-
tive gear. Do not switch on the unit until the
complete filter system has been installed
and the function of the volume-flow control
has been tested.
ƽ
Danger
– When the outgoing air is carried back
into the room, a sufficient ventilation
rate L in the room must be ensured. To
comply with the required limit values the
carried back volume flow must be 50%
of the fresh air volume flow (room vol-
ume V
R
x ventilation rate L
W
) at maxi-
mum. Without a specific ventilation
system the following applies: L
W
=1h
–1
.
– Only persons trained in the use of the
machine and the handling of substanc-
es for which the machine is to be used
including training in the safe disposal of
the sucked-in material may use the ma-
chine.
Device elements Symbols on the machine
Do not suck in any ignition
sources! Suitable for suction
of combustible dusts of the
dust explosion classes in
Zone 22.
Flat fold filter
Order No.
6.904-283.0
Dust disposal bag
Order No.
6.907-347.0
