500-E installation / opEration / sErvicE manual • 5.
1. An identification tag is permanently mounted on
the cabinet.
2. Plug the unit into a properly grounded
receptacle ONLY. Arcing will occur when
connecting or disconnecting the unit unless
all controls are in the “OFF” position.
3. Position the unit so the cord is easily accessible
in case of any emergencies. If necessary, a proper
receptacle or outlet configuration, as required
for the unit, must be installed by a licensed
electrician in accordance with applicable, local
electrical codes.
D A N G E R
ENSURE POWER SOURCE
MATCHES VOLTAGE STAMPED
ON APPLIANCE NAMEPLATE.
C A U T I O N
THIS SECTION IS PROVIDED FOR THE ASSISTANCE
OF QUALIFIED SERVICE TECHNICIANS ONLY AND
IS NOT INTENDED FOR USE BY UNTRAINED OR
UNAUTHORIZED SERVICE PERSONNEL.
D A N G E R
To avoid electrical shock, this
appliance MUST be adequately
grounded in accordance with local
electrical codes or, in the absence of
local codes, with the current edition
of the National Electrical Code ANSI/
NFPA No. 70. In Canada, all electrical
connections are to be made in
accordance with CSA C22.1, Canadian
Electrical Code Part 1 or local codes.
D A N G E R
IMPROPER INSTALLATION,
ALTERATION, ADJUSTMENT,
SERVICE, OR MAINTENANCE COULD
RESULT IN SEVERE INJURY, DEATH,
OR CAUSE PROPERTY DAMAGE.
READ THE INSTALLATION,
OPERATING AND MAINTENANCE
INSTRUCTIONS THOROUGHLY
BEFORE INSTALLING OR SERVICING
THIS EQUIPMENT.
Wire diagrams are located inside the bonnet of the unit.
E L E C T R I C A L
I N S T A L L A T I O N
ELECTRICAL
500-E/HD
voltage phase cycle / hz amps kW plug config .
125 ( agcy ) 1 60 4.0 0.5 NeMa 5-15 p
15 a -125 v plug
208-240 ( agcy ) 1 50/60 5.0 1.2 NeMa 6-15 p
at 208v 50/60 4.4 0.9 15
a
-250
v plug
at 240v 50/60 5.0 1.2
230 ( agcy ) 1 50/60 4.8 1.1 cee 7/7
220-230 v plug
500-E/DELUXE
voltage phase cycle / hz amps kW plug config .
125 (
agcy
) 1 60 4.8 0.6
NeMa
5-15
p
15 a -125 v plug
208-240V
at 208 1 50/60 3.4 0.8 NeMa 6-15 p
at 240 1 50/60 3.0 0.6 15 a -250 v plug
230 ( agcy ) 1 50/60 3.3 0.8 cee 7/7
220-230 v plug
For CE approved units: To prevent an electrical
shock hazard between the appliance and other
appliances or metal parts in close vicinity, an
equalization-bonding stud is provided. An
equalization bonding lead must be connected to
this stud and the other appliances / metal parts
to provide sufficient protection against potential
difference. The terminal is marked
with the following symbol.
NOTE : CE approved appliances must be
connected to an electrical circuit that is
protected by an external GFCI outlet.
