500-E
installation
/
opEration
/
sErvicE
manual
• 16.
PART
DESCRIPTION
#4873
125V
#4878
208-240V
#4879
230V
CB-3045 CABLE HEATING ELEMENT
—
85 feet
112 feet
CB-3044 CABLE HEATING ELEMENT
52 feet
—
—
CR-3226 RING CONNECTOR
4
4
6
IN-3488
INSULATION CORNER
1 foot
1 foot
1 foot
BU-3105 SHOULDER BUSHING
4
4
6
BU-3106 CUP BUSHING
4
4
6
ST-2439 STUD
4
4
6
NU-2215 HEX NUT
8
8
12
SL-3063 INSULATING SLEEVE
4
4
6
TA-3540 ELECTRICAL TAPE
1 roll
1 roll
1 roll
HEAT CABLE REPLACEMENT SERVICE KITS
a
c
d
e
f
g
h
i
j
l
m
b
k
ITEM
DESCRIPTION
PART NO. QTY ITEM
DESCRIPTION
PART NO. QTY
1
CONTROL PANEL
PE-25464
1
8
CASING
1001383
1
2
HINGE
HG-2015
2
9
DOOR HANDLE STRIKER ONLY
HD-2575
1
3
DOOR GASKET
E2132GS
1
10
CARRY HANDLES
HD-2010
4
4
DOOR HANDLE WITH STRIKER
HD-2007
1
11
CARRY HANDLE BACKER
11017
4
5
DOOR WITH WINDOW
E5078
1
12
SENSOR
SN-33541
1
6
SIDE RAILS
SR-25477
2
13
SENSOR BLOCK
BK-24427
1
7
FEET
BM-22606
4
14
TOP
1001349
1
Part numbers and drawings are subject to change without notice.
Exterior View
E L E C T R O N I C C O N T R O L
S E R V I C E
Part numbers and drawings are subject to change without notice.
