Alto-Shaam TY2-96 User Manual

Ty2-96, Ty2sys-96, Series

background image

TY2-96

SERIES

TY2SYS-96

SERIES

HEATED DISPLAY SYSTEMS

ITEM NO

. _______________________

The display case is constructed of 18 gauge, non-magnetic stainless steel. A tempered glass front encloses the display case

and can be lifted to a 90 degree angle for easy cleaning. Removable, sliding glass doors on the operator side are included.

Sliding door tracks have a “clean sweep” cutout allowing for easy cleaning and crumb removal. Framed end glass with

rubber gasket material protects glass edges from chipping and breakage. The base is divided into three (3) individually

managed heat zones with each zone controlled by a separate thermostat with a range of 1 through 10 and heat-on indicator

light. Overhead lights are controlled by ON/OFF switches in three (3) light zones. Two (2) 125V plug outlets are available

as an option on 120/208-240V units only. Counter-top display cases include one set of 4" (102mm) legs.

TY2-96 - 96" (2438mm) length

TY2SYS-96 - 96" (2438mm) length, with base

TY2-96/PL - 96" (2438mm) length, 23-3/4" (603mm) self-service opening on left side of case front

TY2SYS-96/PL - 96" (2438mm) length, with base, 23-3/4" (603mm) self-service opening on left side of case front

TY2-96/PR - 96" (2438mm) length, 23-3/4" (603mm) self-service opening on right side of case front

TY2SYS-96/PR - 96" (2438mm) length, with base, 23-3/4" (603mm) self-service opening on right side of case front

HALO HEAT … a controlled, uniform heat source that gently

holds and surrounds food for better appearance, taste, and longer

holding life.

Holds and displays hot food fresh and moist for hours —

without adding water.

Expandable system to meet your specific requirements.

Matches profile of leading refrigerated display case.

HOT DISPLAY CASE

— Curved glass styling.

— Displays hot food without condensation on glass.

— Thermostatically controlled heat source radiates from the

base of the display case in multiple heat zones.

— Overhead light zones with shatterproof coated bulbs.

— Holds a full range of standard (gastronorm) pan sizes, full-size

or half-size sheet pans.

— Tempered sliding glass doors reflect heat back into the products

and mirror the display to enhance merchandising effect.

DECORATOR BASE

— Standard black painted front and end panels.

SELF-SERVICE HOT DISPLAY

— Customer self-service opening is available on right side or

left side of case.

— Front mounted heat-guard provides customer protection.

W164 N9221 Water Street • P.O. Box 450 • Menomonee Falls, Wisconsin 53052-0450 • U.S.A.

PHONE

: 262.251.3800 800.558.8744

U

.

S

.

A

./

CANADA

FAX

: 262.251.7067 800.329.8744

U

.

S

.

A

.

ONLY

www.alto-shaam.com

P R I N T E D I N U

.

S

.

A

.

D U E TO O N G O I N G P R O D U C T D E V E L O P M E N T

,

S P E C I F I C AT I O N S A R E S U B J E C T TO C H A N G E W I T H O U T N O T I C E

.

#56 - 03/08

ANSI/NSF 4

TY2-96

TY2SYS-96

FACTORY INSTALLED OPTIONS

The system base is not sold as a separate

item. Order the full TY2SYS model to

receive the base.

Panel Color Choices

Specify color choice:

Black, standard

Stainless Steel, optional

Custom Color, optional
