ENGLISH

Under extreme load or temperature, damaged replacement batteries may leak battery fluid. After

contact with battery fluid, immediately wash the area with soap and water. Upon eye contact,

immediately rinse thoroughly for at least 10 minutes and seek immediate medical attention!

Intended use

The ROCAM® TV inspection system is solely for inspecting empty, cleaned pipes, hollow cavities

and hollow spaces, as indicated under „Technical data / Applications“. Other uses are prohibited.
Do not leave camera probes in the sun for extended periods. This can damage the camera modu-

le! All applicable standards and regulations must be observed.
Among others, these particularly include:
- Law on technical equipment (Equipment Safety Act) and associated regulations
- Low Voltage Directive
- UVV VBG 1 „General regulations“
- UVV VBG 4 „Electrical systems and equipment“
- Guidelines for work in containers and confined spaces (BG rule 77), Guideline for workstations

4. Technical data / Applications

Description:

ROCAM 3 Multimedia

Power consumption:

1.2 A

Working temperature (plugged in):

-20°C to 50°C

Working temperature (battery):

0°C to 50°C

Storage temperature (w/o battery):

-30°C to 50°C

Dimensions (LxWxH):

600 x 400 x 365 mm

Weight with battery:

18 kg

Monitor:

10.4“ colour LCD TFT, removable

SL30 camera module:

¼” CCIQ colour PAL/NTSC

SL40 camera module:

¼” CCD colour PAL/NTSC

Camera head diameter:

30 mm / 40 mm

Resolution, SL30:

720 x 576

Resolution, SL40:

720 x 576

Lighting SL30:

25 LEDs, 175 LUX, continuously dimmable

Lighting SL40:

36 LEDs, 666 LUX, continuously dimmable

Video/photo format:

QuickTime mov, JPEG-2000

Connections:

2x USB 2.0; 2.5 mm latch

Data entry:

USB keyboard

Metre display:

digital, continuous

Slide cable length:

30 m

Slide cable diameter:

7.0 mm

Battery voltage:

12 V

Battery capacity:

6 Ah

Pipe diameter:

Ø 35 – 150 mm

Operating voltage:

100 to 240 VAC 50 to 60 Hz / 12 VDC

Positioning transmitter:

33 kHz, bolt-on

Protection class:

IP54

Included in delivery: ROCAM 3 TV inspection system, guide ball, battery, installation CD, quick

start guide, 4 GB USB stick, positioning probe.
