88 DEUTSCH 88
S/N Name Code
1 Hexagonal bolt M10x25 8873101
2 Spring washer 10 8873102
3 Flat washer A level 10 8873103
4 Triangle bracket 8873104
5 Stopping block A 8873105
6 Bracket pipe 8873106
7 Guide column 8873107
8 Hexangular bolt M8x20 8873108
9 Bolt M10x30 8873109
10 Stopping block B 8873110
11 Tighten screw 8873111
12 Adjust screw cap 8873112
13 Handle 8873113
14 C-type cross screw M8x10 8873114
15 Triangle bracket base 8873115
16 Bearing 6205 8873116
17 Bearing retainer ring 8873117
18
Chock 8873118
SPARE PARTS
