ROTHENBERGER ROGROOVER 2 - 12 - Manual (Page 85)

84 DEUTSCH 84
S/N Name Code
1 Nameplate 8873001
2 Loop 8873002
3 Safety cover 8873003
4 Slotting screw M5x8 8873004
5 Slotting screw M5x16 8873005
6 Cable quick connector 8873006
7 Reduction motor 750W 8873007
8 Hexagonal nut C level M10 8873008
9 Spring washer 10 8873009
10 Flat washer A level 10 8873010
11 Bolt M10x60 8873011
12 Bolt M10x75 8873012
13 Support foot 8873013
14 Hexagonal screw M10x25 8873014
15 Base 8873015
16 Jockey pulley holder assembly 8873016
17 Electric link 8873017
18 Intermediate link 8873018
19 Shaft link 8873019
20 Hexagonal screw M6x12 8873020
21 Rear cover 8873021
22 Roller bearing 32010 8873022
23 Main shaft 8873023
24 Flat key 8x25 8873024
25 Flat key 6x30 8873025
26 Bushing ø80 8873026
27 United head 8873027
28 Bushing ø75 8873028
29 Needle bearing 4074109 8873029
30 Plane needle bearing 889109 8873030
31 Fore cover 8873031
32 Knurl wheel 8873032
33 Main shaft fastening nut 8873033
34 Hexagonal screw M10x35 8873034
S/N Name Code
35 Oil pump assembly 8873035
36 Hexagonal screw M5x16 8873036
38 Piston fixed ring screw 8873038
39 Hexagonal screw M6x30 8873039
40 Screw fixed ring 8873040
41 Adjust screw 8873041
42 Hexagonal head tap bolt M10x45 8873042
43 Guide rail bar 8873043
44 Hexagonal screw M10x20 8873044
45 Hexagonal screw M5x10 8873045
46 Hexagonal fasten screw M10x30 8873046
47 Slide 8873047
48 Feather key 8873048
49 Roller frame 8873049
50 Pinch roller shaft 8873050
51 Oil cup M10x1 8873051
52 Pinch roller 8873052
53 Needle bearing 4084105 8873053
54 Power hearing safety cover 8873054
55 Hexagonal screw M10x50 8873055
56 Booster bloosk 8873056
57 Tool box 8873057
58 Platform support blok 8873058
59 Grip 8873059
60 Hexagonal screw M10x25 8873060
61 AC contraltor 8873061
62 Thermal protector 8873062
63 Foot switch 8873063
SPARE PARTS
