- 35 - Using the Scanner: Using the SA-20 S
TRIP
F
ILM
A
DAPTER
Using the SA-20 S
TRIP
F
ILM
A
DAPTER
35 mm film-strips of from two to six frames in length can be
scanned using the strip-film adapter. Insert the adapter into the
scanner’s adapter slot as shown below, sliding it in until it con-
tacts the back of the slot. Push the adapter until the connector
on the rear of the adapter is seated securely in the socket at the
back of the slot.
A plastic tray is provided with the strip-film adapter to catch film
ejected from the scanner. If the scanner has been installed on
its side, this tray can be attached to the adapter by inserting the
hooks on the back of the tray into the holes provided on the
bottom of the adapter and then pulling the tray slightly forward.
1. Insert hooks
2. Pull forward to latch
