Part No. 0110-003022
Page 7
Rev 1 3-5-13 DSL
AIR INJECTION LOOM INFORMATION
Note: Should you require replacement of the stock air injection looms, your local GM parts
department may be able to provide replacement air injection looms using these part numbers:
Dual AIR Pump Single AIR Pump
Driver side: 14102115 Driver side: 330544
Passenger side: 14102114 Passenger side: 330544
HEAT RISER INFORMATION
What is a heat riser?
The heat riser is a valve that closes off the exhaust on one bank of a V8’s cylinders when the
engine is cold. This routes the hot exhaust gases from the closed-off bank through the
exhaust cross-over at the center of the intake manifold and out through the exhaust manifold
on the “open” side. The exhaust heat helps the gasoline in the cold intake manifold reach
evaporation temperature more quickly, eliminating “puddling” of raw gasoline in the intake
manifold and making the vehicle much more driveable when it is cold. As the engine warms
up, the valve opens, allowing the
exhaust to flow out through both headers.
What is an “E.F.E. valve”?
“E.F.E.” stands for Early Fuel Evaporation, and “E.F.E. valve” is often considered to be
Another name for the heat riser. Some vehicles, however, have what is referred to as an
“E.F.E. system”. An E.F.E. system might include both a heat riser in the exhaust manifold and
a hot air pickup that draws the
engine’s intake air across one of the exhaust manifolds to
preheat it during cold start conditions. Whatever combination your vehicle came equipped with
in its stock configuration is what must be reinstalled and reconnected when headers are
installed in order for your vehicle to be smog legal. If in doubt, consult your new-car dealership
parts department or an authorized smog inspection/maintenance station.
What controls the operation of the heat riser?
There are two types of heat risers: mechanical and vacuum. The mechanical types use a bi-
metallic strip which works like a heat-sensitive spring, opening the valve when it gets hot
enough. The vacuum type uses a vacuum canister similar to the vacuum advance on an
ignition distributor. Vacuum routed through a heat-sensitive switch (usually monitoring engine
coolant temperature) pulls the valve closed when the engine is cold, and then allows it to open
by shutting off the vacuum supply when normal operating temperature is reached.
