Aiwa DINA Z-A60 - Manual (Page 19)

ENGLISH
19
En
SPECIFICATIONS
Main unit CX-ZA60
FM tuner section
Tuning range 87.5 MHz to 108 MHz
Usable sensitivity (IHF) 13.2 dBf
Antenna terminals 75 ohms (unbalanced)
AM tuner section
Tuning range 530 kHz to 1710 kHz (10 kHz
step)
531 kHz to 1602 kHz (9 kHz
step)
Usable sensitivity 350 µV/m
Antenna Loop antenna
Amplifier section
Power output Rated: 80 W + 80 W (6 ohms,
T.H.D. 1%, 1 kHz)
Reference: 120 W + 120 W (6
ohms, T.H.D. 10%, 1 kHz)
Total harmonic distortion 0.15 % (50 W, 1 kHz, 6 ohms,
DIN AUDIO)
Inputs VIDEO/AUX/PHONO: 500 mV
Outputs SPEAKERS: accept speakers
of 6 ohms or more
\ (stereo jack): accepts
headphones of 32 ohms or
more
Cassette deck section
Track format 4 tracks, 2 channels stereo
Frequency response 50 Hz – 12500 Hz
Recording system AC bias
Heads Deck 1: Playback head × 1
Deck 2: Recording/playback
head
× 1, erase head × 1
Compact disc player section
Laser Semiconductor laser ( λ = 780
nm)
D-A converter 1 bit dual
Signal-to-noise ratio 85 dB (1 kHz, 0 dB)
Harmonic distortion 0.05 % (1 kHz, 0 dB)
Wow and flutter Unmeasurable
General
Power requirements 120 V AC, 60 Hz
Power consumption 95 W
Dimensions of main unit 360 Ч 395.3 Ч 350.6 mm
(W × H × D) (14 1 /
4
x 15 5 /
8
x 13 7 /
8
in.)
Weight of main unit 9.8 kg (21 lb.)
Speaker system SX-ZA60
Cabinet type 3 way, bass reflex
Speakers Woofer:
170 mm (6
3 /
4
in.) cone type
Tweeter:
60 mm (2
3 /
8
in.) cone type
Super tweeter:
20 mm (
13 /
16
in.) ceramic type
Impedance 6 ohms
Output sound pressure level 89 dB/W/m
Dimensions (W
× H × D) 260 Ч 495 Ч 280 mm
(10 1 /
4
x 19 1 /
2
x 11 1 /
8
in. )
Weight 5.5 kg (12 lbs. 2 oz.)
Specifications and external appearance are subject to change
without notice.
COPYRIGHT
Please check the laws on copyright relating to recordings from
discs, radio or external tape for the country in which the machine
is being used.
GENERAL
NOTE
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of
the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on circuit different from
that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician
for help.
CAUTION
Modifications or adjustments to this product, which are not
expressly approved by the manufacturer, may void the user's
right or authority to operate this product.
