AR6410LBL User Guide
The AR6410LBL 6-channel ultra micro receiver with integrated long throw servos,
brushless speed control and X-Port ™ technology is designed for ultra micro
aircraft. Featuring DSM2 ™ /DSMX ® technology the AR6410LBL is compatible with
all Spektrum ™ , JR ® , E-flite ® and ParkZone ® 2.4GHz DSM2/DSMX technology
transmitters.
NOTICE: The AR6410LBL receiver is not compatible with the DX6 park flyer radio
system.
Features
• 6-channel ultra micro receiver
• Two integrated linear long throw servos (elevator and rudder)
• Integrated programmable brushless speed control
• Weighs just 7.8 grams
• Compatible with optional Spektrum ultra micro linear servos
• Smart Bind ™ technology
• X-Port allows for future expansion
Applications
The AR6410LBL is designed for ultra micro aircraft and is ideal for scratch-built
ultra micro projects. It utilizes a two-cell LiPo battery and can be used with the
integrated brushless speed controller to power a brushless motor up to 3.9-amps
of continuous current. An integrated X-Port feature allows for future expansion.
When X-Port is active, CH5 and CH6 are not available; however, reversed aileron
(CH2) is still available.
Specifications:
AR6410LBL
Type: DSMX ultra micro receiver with integrated brushless speed controller and
two linear servos
Channels: 6 or 4 channels, plus X-Port
Modulation: DSM2/DSMX
Dimension (WxLxH): 37.60 x 28.55 x 8.00mm
Weight: 7.8 g
Input Voltage Range: 2-cell LiPo 6.4 to 8.4V
Antenna Length: 31mm
Resolution: 1024 DSM2, DSMX
Compatibility: All DSM2 and DSMX aircraft transmitters
Servos:
Force: 2.8 oz (79 g)
Stroke: 9.1mm
Speed: 0.14 sec
Stall current: 80mA at 4.2V without load
