L. Adjusting the Cyclic Swashplate Limit
Menu point (L) adjusts the maximum possible tilting of the swashplate for aileron
and elevator. The deflection is limited in a circular path, similar to a cyclic ring
function, preventing swashplate binding at full aileron and elevator travel.
1. Carefully move the sticks for aileron, elevator and pitch to all maximum
endpoints. Watch for binding or lack of movement in the swashplate, linkage
rods and servos.
2. Move the rudder stick right or left to increase or decrease the aileron and
elevator throw limiter. Always try to achieve the maximum possible cyclic
throw without causing binding.
3. The Status-LED should still be Blue when the swashplate is at the maximum
limit. If the Status-LED is Purple or Off, you must mechanically adjust the
helicopter to increase the available throw.
ImpoRTANT: If you make any modifications to menu points (G), (J) or (K) in the
future, you must repeat menu point (L) again.
Push the setup button to save the selection and move to menu point (M).
m. Setting the Swashplate Sensor Directions
1. Tilt the helicopter forward. The swashplate should tilt backward.
2. Tilt the helicopter backward. The swashplate should tilt forward.
3. Roll the helicopter left. The swashplate should roll right.
4. Roll the helicopter right. The swashplate should roll left.
5. If the swashplate does not move in the correct direction, you will need to
reverse the sensor direction by moving the rudder stick to select one of the
following options. There are four options:
Status-LED Elevator Aileron
OFF reversed reversed
Purple Solid reversed normal
Red Solid normal reversed
Blue Solid normal* normal*
6. Repeat Step 5 until both sensors are working in the correct direction.
7. Push the setup button to save the selection and move to menu point (N).
*=Factory
Setting
