SPEKTRUM DX3R PROGRAMMING GUIDE
IdenTIfyIng buTTons, swITChes and ConTrols
1
2
3
4
14
13
5
6
7
8
9
15
10
11
12
1: Antenna
2: LCD Screen
3: Switch D/Steering Trim
4: Switch E/Brake
5: Button F/Timer
6: Charge Jack
7: Switch A/Throttle Trim
8: Switch B/Steering Trim
9: Switch C/Aux 3 Linear
10: Rolling Selector
11: Battery Door
12: On/Off Switch
13: Throttle Trigger
14: Steering Wheel
15: Steering Tension Adjustment
