26 SPEKTRUM DX3R PROGRAMMING GUIDE
TrIM sTep
User Name
01: Model 01
Trim Step
Steering 4
Throttle 4
≤
The Trim Step function allows the user to adjust the
sensitivity of the steering and throttle/brake trims.
It’s important to understand that Trim Step affects the
amount the servo travels with each click of the trim
but has no effect on the total trim travel. In essence,
Trim Step changes the number of trim steps that are
available within the trim stroke and has no effect
on the total trim travel. Trim Step allows the user
to fine-tune the steering, throttle and brake trims to
meet the needs of specific applications.
To aCCess The
TrIM sTep funCTIon:
In the List screen use the roller to highlight the Trim
Step function.
Press the roller to access the Trim Step function. The
above screen will appear.
Use the roller to select the desired channel that you
wish to adjust the trim step.
Press the roller to highlight that channel and the
surrounding box will flash then rotate the roller to
adjust the Trim Step value. The adjustment range
is from 1 to 20 (very fine to coarse trim steps). The
default setting is 4.
To return to the main screen press and hold the
roller for more than three seconds.
reseT
Model
01: Model 01
Reset
User Name
Parameters
≤
The reset function is used to reset the Model
Memory that is selected, the User Name, back to the
factory defaults, and the Parameters function is used
to recalibrate the transmitter’s steering and brake
potentiometers.
To aCCess The reseT funCTIon:
In the List screen use the roller to highlight the Reset
function.
The above screen will appear.
Rotate the roller to access the desired function that
you choose to reset.
Model:
Reset the model memory that is
displayed
User Name: Reset the user name
Parameters: Recalibrate the transmitter’s steering
and brake potentiometers
Press the roller to access the selected, reset
function. If the model was selected use the roller
to select the desired model memory that you
wish to reset. Then press the roller to access the
Confirm screen.
