28 SPEKTRUM DX3R PROGRAMMING GUIDE
MonITor
User Name
01: Model 01
ST +129
TH +0
AX +0
Monitor
≤
A servo monitor is available that displays the
servo output positions graphically and digitally.
This monitor can be useful in troubleshooting
setups, displaying mixing functions and how they
interrelate, etc.
To aCCess The MonITor funCTIon:
In the List screen use the roller to highlight the
Monitor function.
Press the roller to access the Monitor function. The
above screen will appear and real time servo output
positions will be displayed.
To return to the Main screen press and hold the
roller for more than three seconds.
sysTeM
System
Switch Select
A B C D E F
Username
◊
Contrast: 10
Voltage Alert
4.0v
User Name
≤
The System function allows the six available
switches (A,B,C,D,E and F) to be programmed to
the desired function. It allows the user name to be
selected, contrast to be adjusted, and the voltage
alarm threshold can be set.
