72 Rapier Switch Software Reference
Software Release 2.5.1
C613-02025-00 REV B
AppleTalk
AppleTalk is enabled with a special feature license. To obtain a special feature license
contact an Allied Telesyn authorised distributor or reseller.
To create an AppleTalk port (interface) associated with the admin VLAN, use
the command:
ADD APPLE PORT INTERFACE= vlan11
The command:
SHOW APPLE PORT
displays information about the ports configured for AppleTalk (Figure 9 on
page 72).
Figure 9: Example output from the SHOW APPLE PORT command.
Resource Reservation Protocol (RSVP)
RSVP is enabled with a special feature license. To obtain a special feature license contact
an Allied Telesyn authorised distributor or reseller.
The Resource Reservation Protocol (RSVP) enables the receiver of a traffic flow
to make the resource reservations necessary to ensure that the receiver obtains
the desired QoS for the traffic flow.
RSVP is disabled by default. To enable RSVP, use the command:
ENABLE RSVP
Each IP interface that is to receive and process RSVP messages and accept
reservation requests must be enabled. To enable RSVP on the admin VLAN,
use the command:
Appletalk Port Details
------------------------------------
Port Number .............. 1
Interface ................ vlan11
ifIndex .................. 1
Node ID .................. 217
Network Number ........... 22
Network Range Start ...... 22
Network Range End ........ 22
State .................... ACTIVE
Seed ..................... NO
Seed Network Start ....... 0
Seed Network End ......... 0
Hint ..................... YES
Hint Node ID ............. 179
Hint Network ............. 22
Default Zone ............. -
Zone List is Empty
------------------------------------
