55
Appendix A
Cables
Specifications
Table 7 100Base-TX Twisted Pair Cable
Cable Type Category Connector
100 Ohm UTP, 22 - 26 AWG
0.4 - 0.6 mm, 2 pairs 5 certified male, 8-pin RJ-45
Table 8 10Base-T Twisted Pair Cable
Cable Type Category Connector
100 Ohm UTP, 22 - 26 AWG
0.4 - 0.6 mm, 2 pairs 3, 4, 5 male, 8-pin RJ-45
Table 9 100Base-SX and 1000Base-SX Fiber Cable
Cable Type Connector
50/125 or 62.5/125 micron
multimode SC
Table 10 1000Base-LX Fiber Cable
Cable Type Connector
10/125 micron single-mode SC
