AT-8324SX Installation Guide
21
Description of Hardware
10Base-T/
100Base-TX Ports
These ports are dual-speed RJ-45 ports with built-in wiring crossovers
(MDI-X). Workstations and servers can be connected to these ports with
straight-through cable. When connecting to another switch or a hub,
you can connect to a port on the attached device that does not have
built-in wiring crossovers (MDI) or use crossover cabling (see Appendix A
for a pin-out description of crossover cable).
Each of these ports support auto-negotiation, so the optimum
transmission mode (half- or full-duplex) and data rate (10 or 100 Mbps)
are selected automatically. If a device connected to one of these ports
does not support auto-negotiation, the communication mode of that
port can be configured manually.
Status LEDs
The LEDs, which are located on the front panel for easy viewing, are
described in the following table.
Table 1 Port and System Status LEDs
LED Condition Status
PWR ON Switch is receiving power.
RPS ON Redundant power is ON and the RPS is in the
backup or active mode.
OFF Redundant power is OFF or has failed.
MGMT ON Agent is operational.
RJ-45 Ports
LINK ON Port has established a valid network
connection.
Amber Valid 10 Mbps connection.
Green Valid 100 Mbps connection.
Flashing Port has been partitioned due to an abnormal
network condition, or manually disabled.
ACTIVITY
1
ON Traffic is passing through the port.
FULL DUP
1
ON Port has been set to full-duplex.
FLOW
1
ON Flow control enabled.
