Allied Telesis FastSwitch8 - Manual (Page 19)

FastSwitch8 Installation Guide
13
Port Pinouts
Straight-through Cable
Crossover Cable
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
TD +
TD -
RD +
Not Used
TD +
TD -
RD +
Not Used
Not Used Not Used
Not Used Not Used
Not Used Not Used
RD - RD -
RJ45 PIN RJ45 PIN
Per IEEE 802.3 specifications
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
D +
TD -
RD +
Not Used
TD +
TD -
RD +
Not Used
Not Used Not Used
Not Used Not Used
Not Used Not Used
RD - RD -
RJ45 PIN RJ45 PIN
Per IEEE 802.3 specifications
