Technical Specifications
18
Agency Certifications
EMI/RFI: FCC Class B, EN55022 Class B,
VCCI Class B
Electrical Safety: EN60950 (TUV), UL1950 (
c
UL
us
),
CE Compliant
Immunity: EN55024, VCCI Class B
Fiber Optic Port Specifications
Table 5 through Table 7 list the specifications for the 10Base-FL fiber optic
port.
Table 5 Fiber Optic Transmitter
Model Fiber
Type
1
1. MMF = Multimode Fiber
Fiber
Optic
Diameter
(microns) Optical
Wavelength
Launch Power (dBm)
2
2. The launch power is measured at one meter from the transmitter.
Max. Avg. Min.
AT-LMC10SC
and
AT-LMC10ST MMF 50/125 1310 nm -14.0 -20.3 -22.5
MMF 62.5/125 1310 nm -14.0 -16.8 -19.0
Table 6 Fiber Optic Receiver
Model Fiber
Type
1
1. MMF = Multimode Fiber
Fiber
Optic
Diameter
(microns) Optical
Wavelength
Receive Power (dBm)
Min. Typical Saturation
AT-LMC10SC
and
AT-LMC10ST MMF 50/125 1310 nm -31.8 -34.4 -14.0
MMF 62.5/125 1310 nm -31.8 -34.4 -14.0
