Back-to-Back Topology
Figure 5 illustrates two media converters in a back-to-back configuration.
Figure 5 Back-to-Back Topology
RS-232 TERMINAL PO RT STATUS
10BASE-T / 100 BASE-TX FAST ETHERN ET SWITCH
PORT ACTIVITY
10BASE-T / 10 0BASE-TX
RS-232 TERMINAL POR T STATUS
10BASE-T / 100B ASE-TX FAST ETHERNE T SWITCH
PORT ACTIVI TY
10BASE-T / 100 BASE-TX
TX RX
AT-LMC10SC ETHERNET MEDIA CONVERTER
CLASS 1 LASER PRODUCT DO NOT STARE INTO BEAM
10Base-FL 10Base-T
PWR
REC
LNK
MDI-X MDI
REC
LNK
TX RX
AT-LMC10SC ETHERNET MEDIA CONVERTER
CLASS 1 LASER PRODUCT DO NOT STARE INTO BEAM
10Base-FL 10Base-T
PWR
REC
LNK
MDI-X MDI
REC
LNK
Cable Legend
10 Mbps
10 Mbps (Fiber)
100 m (328 ft)
100 m (328 ft)
AT-LMC10SC
AT-LMC10SC
AT-8224XL
AT-8224XL
2 km (1.2 mi)
