AT-FS708LE Installation Guide

6. Power ON the end-nodes connected to the

switch.

7. Check that the LNK/ACT LED for each port

on the switch is green. If a LED is OFF, refer
to “Troubleshooting” on page 32.

The AT-FS708LE switch is now ready for use.

Installing the Unit on a Wall

For wall-mount installation, you can position
the switch vertically or horizontally on the wall
using the keyhole cutouts in the bottom of the
switch chassis.

Note

For wall-mount installation, you must
supply the two screws and plastic
anchors or other material necessary to
physically mount the switch to the wall.

1. If attached, remove the rubber feet, data

cables, and power cord from the switch.

2. Select a wall location for the switch.

3. Install two plastic anchors and two pan-head

screws into the wall, separated by 5
centimeters (approximately 2 inches).
