22
Network Topologies
The AT-FS708LE switch can be used in a
variety of network topologies, such as a
standalone or cascade. Both topologies are
described below.
Standalone Topology
Figure 3 illustrates the standalone topology
where each end-node is directly connected
directly to a 10/100Base-TX port on an
AT-FS708LE switch. This gives each end-node
a dedicated 10 Mbps or 100 Mbps link.
Figure 3 Standalone Topology
5x 4x 3x 2x 1x 6x 7x 8x
Workstations
Workstations
Server
10 Mbps
100 Mbps
