Allied Telesyn
AT-VIEW PLUS
VLAN MANAGER
6.11 AT-RG600 Series
Topics:
•
•
6.11.1 VLAN Information Window
The VLAN Information Window displays the following attributes for each VLAN definition:
Column Name
Description
Name
This is the name of the VLAN.
Identifier
This is the unique identifier of the VLAN.
Tagged Ports
This is a list of the tagged member ports of the VLAN.
Untagged Ports
This is a list of the untagged member ports of the VLAN.
Priority
This indicates the 802.1p Priority.
Status
This indicates the status of the VLAN.
•
dynamic
•
static
Note
- VLANs whose names start with a number cannot be deleted.
6.11.2 Add/Modify VLAN Dialogs
The Add/Modify VLAN Dialogs have the following Input Fields:
Input Field
Valid Values
Length
Name (cannot be
modified)
• Alphanumeric characters
• Underscore ("_")
• Dash ("-")
Note
- VLAN names cannot start with a digit and
cannot contains dots '.' or the slash symbols'/'.
1 - 15 characters
Identifier (cannot
be modified)
• 1 - 512 (AT-RG656BD)
• 1 - 4094 (AT-RG613TX / AT-RG613SH)
-
Priority (cannot be
modified)
• 0 - 7
-
PN 613-50666-00 Rev A
Page 51 of 52
