Allied Telesyn AT-VIEW PLUS
VLAN MANAGER
6.8 AT-8700XL/AT-8800/Rapier Series
Topics:
• VLAN Information Window
• Add/Modify VLAN Dialogs
6.8.1 VLAN Information Window
The VLAN Information Window displays the following attributes for each VLAN definition:
Column Name Description
Name This is the name of the VLAN.
Identifier This is the unique identifier of the VLAN.
Operation Mode This indicates the operation mode of the VLAN.
Tagged Ports This is a list of the tagged member ports of the VLAN.
Untagged Ports This is a list of the untagged member ports of the VLAN.
Uplink Ports This is a list of the uplink ports of the VLAN.
Private Ports This is a list of the private ports of the VLAN.
Status
This indicates the status of the VLAN.
• dynamic
• static
Note - The Operation Mode is not available if the software release version used on AT-8700XL is
2.6.4.
Note - Adding a Private VLAN with a Private Port that has already been associated with the Default
VLAN as a Tagged Port will result to an error. However, the Private VLAN will still be added on
the device with only the Uplink Port configured.
Note - After an Import VLAN operation, the Default VLAN with invalid Untagged Ports will have
successful status.
Note - When performing an Import VLAN operation, if the specified Operation Mode is Normal, the
Uplink Ports and Private Ports fields will be ignored by the application.
PN 613-50666-00 Rev A Page 45 of 52
