Allied Telesyn
AT-VIEW PLUS
VLAN MANAGER
6.10 AT-9800/SwitchBlade Series
Topics:
•
•
6.10.1 VLAN Information Window
The VLAN Information Window displays the following attributes for each VLAN definition:
Column Name
Description
Name
This is the name of the VLAN.
Identifier
This is the unique identifier of the VLAN.
Tagged Ports
This is a list of the tagged member ports of the VLAN.
Untagged Ports
This is a list of the untagged member ports of the VLAN.
Type
This indicates the type of the VLAN.
•
Port-based
•
IP subnet-based
•
Protocol-based
•
MAC address-based
•
Limited protocol-based
Status
This indicates the status of the VLAN.
•
dynamic
•
static
Note
- After Import VLAN operation, Default VLAN with invalid Untagged Ports will have
successful status.
6.10.2 Add/Modify VLAN Dialogs
The Add/Modify VLAN Dialogs have the following Input Fields:
Input Field
Valid Values
Length
Name (cannot be
modified)
• Alphanumeric characters
• Underscore ("_")
• Dash ("-")
1 - 15 characters
PN 613-50666-00 Rev A
Page 49 of 52
