6.4 AT-8324
Topics:
•
•
6.4.1 VLAN Information Window
The VLAN Information Window displays the following attributes for each VLAN definition:
Column Name
Description
Name
This is the name of the VLAN.
Identifier
This is the unique identifier of the VLAN.
This is a list of the tagged member ports of the VLAN that
belong to a specific module on the stack.
This is a list of the untagged member ports of the VLAN
that belong to a specific module on the stack.
Status
This indicates the status of the VLAN.
•
active
•
not in service
•
not ready
•
create and go
•
create and wait
•
destroy
6.4.2 Add/Modify VLAN Dialogs
The Add/Modify VLAN Dialogs display the following Input Fields:
Input Field
Valid Values
Length
Name
• Alphanumeric characters
• Underscore ("_")
• Dash ("-")
Note
- VLAN names must contain at least one (1)
alphabet character.
Note
- "ALL" is a reserved word and cannot be
1 - 19 characters
