AT-GS900/xE Gigabit Ethernet Switch Installation Guide
11
Overview
The AT-GS900/xE switch is an unmanaged five- or eight-port Gigabit
Ethernet switch.
The AT-GS900/xE switch switch offers a range of features and capabilities
that can be used in a variety of network configurations and topologies,
such as:
ˆ Creating small workgroups with dedicated 10 megabits per second
(Mbps), 100 Mbps, and 1000 Mbps links to your network devices, such
as workstations, servers, printers, and routers.
ˆ Interconnecting Ethernet hubs or switches to provide a bridge between
the different workgroups of your network.
ˆ Connecting to other Ethernet switches so that they can be part of a
larger Ethernet network.
ˆ Maximizing your existing network by providing full-duplex operation
over a twisted pair port.
Figure 1 illustrates the front panel of the AT-GS900/5E switch.
Figure 1. AT-GS900/5E Front Panel
Figure 2 illustrates the front panel of the AT-GS900/8E switch.
Figure 2. AT-GS900/8E Front Panel
1036
AT-GS900/5E
5 Port 10/100/1000 Mbps Ethernet Switch
POWER
1 2 3 4 5
1 2 3 4 5
10/100 LINK ACT 1000 LINK ACT FDX HDX COL
1031
AT-GS900/8E
8 Port 10/100/1000 Mbps Ethernet Switch
1 2 3 4 5 6 7 8
1 2 3 4 6 7 8 5
POWER
10/100 LINK ACT 1000 LINK ACT FDX HDX COL
